2x 4-pin Chassis Fan headers
2x 4-pin Radiator Fan headers
2x Addressable Gen 2 header
2x W_PUMP+ headers
4-pin CPU Fan header
4-pin CPU OPT Fan header
6-pin ARGB Gen 2 header to support 2x ARGB Gen 2 headers
10-1 pin System Panel header
Alteration PCIe mode switch
BIOS FlashBack button
BIOS Switch button
Clear CMOS button(s)
FlexKey button
Thermal Sensor header
WB_SENSOR header
Wi-Fi module with an antenna connector
Uwagi do karty sieciowej
ASUS LANGuard
Uwagi do karty dźwiękowej
Dedicated audio PCB layers
ESS ES9219 QUAD DAC
High quality 120 dB SNR stereo playback output and 110 dB SNR recording in
Impedance sense for front and rear headphone outputs
LED-illuminated audio jacks
Premium audio capacitors
Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
Supports up to 32-Bit/384 kHz playback on front panel
SupremeFX Shielding Technology
Port LAN
1x 2,5 Gigabit LAN Realtek®
1x 10 Gigabit LAN Marvell® AQtion
Uwagi do kontrolera SATA
(supports PCIe 4.0 x4 mode)
- DIMM.2_1 slot (Key M) via ROG Q-DIMM.2, type 2230/2242/2260/2280/22110
- DIMM.2_2 slot (Key M) via ROG Q-DIMM.2, type 2230/2242/2260/2280/22110
- M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
- M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 modes
- M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 modes)**
Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10,
Intel® Core™ Ultra Processors(series 2):
Intel® Z890 Chipset:
M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2
PCIEX16(G5)_2 will disabled
SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5
When M.2_3 is enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2
will run x4. When M.2_3 & M.2_4 are enabled, PCIEX16(G5)_1 will run x8 &
Uwagi do WiFi / BT
2x2 Wi-Fi 7 (802.11be)
For Windows 10, only Wi-Fi 6 is supported
For Windows 11, Wi-Fi 7 will require 24H2 or later version for full
Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate.
Supports 2.4/5/6GHz frequency band
Wi-Fi features may vary depending on the operating system
functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E
Uwagi do złącz PCI
(https://www.asus.com/support/FAQ/1037507/)
- 1 x PCIe 4.0x4 slot
- 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 or x8/x4/x4 modes)**
Intel Core Ultra Processors (series 2):
Intel® Z890 Chipset:
M.2_3 & M.2_4 share bandwidth with PCIEX16(G5)_2. When M.2_3 is enabled,
PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will run x4. When M.2_3 & M.2_4
Please check the PCIe bifurcation table on the support site
are enabled, PCIEX16(G5)_1 will run x8 & PCIEX16(G5)_2 will disabled
Maksymalna ilość portów USB 4.0
2
Port Wi-Fi
IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth
Bluetooth V5.4
Uwagi do karty graficznej
For resolution support please check DisplayPort 2.1 specs.bandwidth limited
Graphics specifications may vary between CPU types. Please refer to
Supports max. 8K@60Hz with DSC as specified in HDMI 2.1.
Supports up to 1 x 8K@60HZ(DSC mode)+2 x 4K@60HZ monitors, It is recommend
VGA resolution support depends on processors' or graphic cards' resolution
by DisplayPort™ 2.1 with up to 77.4 Gbit/s
to chain-connect the monitors using a verified Thunderbolt™ cable
www.intel.com for any updates.
Uwagi do procesora
Intel Turbo Boost Max Technology 3.0 support depends on the CPU types
Refer to https://www.asus.com/support/download-center/ for CPU support list
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max 3.0
Złącza PCI Express x4
1
Uwagi do pamięci RAM
ASUS Enhanced Memory Profile III (AEMP III)
Supports DIMM Flex, Supports DIMM Fit, NitroPath DRAM Technology
Supports Intel® Extreme Memory Profile (XMP) memory module
Support up to 8400+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM
Zintegrowana karta dźwiękowa
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
Gniazdo procesora
Socket 1851
Obsługiwane typy procesorów
Intel Core Ultra Processors (series 2)
BIOS
2x 256 Mb Flash ROM, UEFI AMI BIOS; WOL by PME
Standard pamięci
DDR5-8400+ (OC)
Zintegrowany kontroler SATA
Chipset+CPU: 4x SATA III 6Gb/s + 6x M.2
Maksymalna ilość portów USB 3.x
14
Porty USB na panelu tylnym
5x USB 3.1 + 2x USB 3.1 Type-C + 1x USB 3.2 Type-C + 2x Thunderbolt 5 Type-C
Gniazda USB na płycie głównej
2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.1 Type-C (1 port)+ 1x USB 3.2 Type-C (1 port)
Gniazdo zasilania
ATX (24-pin) + 2x ATX12V (8-pin) + PCIe (8-pin)
Wymiary [S x W] (mm)
305 X 277
