Intel Form Factor ATX 12V v2.31 Active PFC(>0.9 typical) Input Voltage: 100-240 Vac(full range) Input Current: 8-4 A Input Frequency: 60-50 Hz 120mm Hydraulic Bearing (HYB) Fan MTBF: >100,000 hours Power Good Signal: 100-500ms Hold Up Time: >16ms Cable Type: Flat, All black
OCP (Over Current Protection) / zabezpieczenie przed przeciążeniem stabilizatora
OPP (Over Power Protection) / zabezpieczenie przeciw przeciążeniowe
OTP (Over Temperature Protection) / zabezpieczenie przed przegrzaniem zasilacza
OVP (Over Voltage Protection) / zabezpieczenie nadnapięciowe
SCP (Short Circuit Protection) / zabezpieczenie przeciwzwarciowe
UVP (Under Voltage Protection) / zabezpieczenie przed zbyt niskim napięciem
Certyfikat
80 PLUS Bronze
Ilość wentylatorów (max)
1 szt.
Maksymalna moc zasilacza
550 W
Standard zasilacza
ATX
Przeznaczenie zasilacza
Komputer stacjonarny
Sprawność
85% pod typowym obciążeniem
Średnica wentylatora
120 mm
Wtyczka zasilania
ATX 20+4pin
Modularność
Brak
Złącza zasilacza
4 Pin Peripheral x 3 + 4-Pin floppy x 1 : 500mm+120mm+120mm+120mm*1
ATX/MB 20+4 Pin x 1 : 550mm*1
CPU/EPS 4+4 Pin x 1 : 600mm*1
PCI-e 6+2 Pin x 2 : 550mm+150mm*1
SATA x 6 : 500mm+120mm+120mm*2
