Power Supply (PoE): 24V, 0.5A Max. Power Consumption: 8W Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return) Operating Frequency (Worldwide): 5170-5875 MHz Gain: 14.6-16.1 dBi Networking Interface: (2) 10/100 Ethernet Ports Processor Specs: Atheros MIPS 74Kc, 560 MHz Memory: 64 MB DDR2, 8 MB Flash Cross-pol Isolation: 22 dB Minimum Max. VSWR: 1.6:1 Beamwidth: 43° (H-pol) / 41° (V-pol) / 15° (Elevation) Enclosure: Outdoor UV Stabilized Plastic Mounting: Pole-Mount (Kit Included) Operating Temperature: -30 to 75° C (-22 to 167° F) Operating Humidity: 5 to 95% Noncondensing Wireless Approvals: FCC Part 15.247, IC RS210, CE RoHS Compliance: Yes Shock & Vibration: ETSI300-019-1.4 Throughput: 150+ Mbps Range: 15+ km
Indeks
NSM5
W magazynie
3 Przedmioty
Opis
Zawiera baterię / akumulator
Nie
Wymiary [G x S x W] (mm)
31 x 80 x 294
Moc wyjściowa
16 dBi
Tryb pracy
Access Point / Punkt dostępowy
Rodzaj urządzenia bezprzewodowego
Access Point / Punkt dostępowy
Obsługiwane protokoły / Zgodność z normami
IEEE 802.11a Połączenie bezprzewodowe do 54 Mb/s, częstotliwość 5 GHz
IEEE 802.11n Połączenie bezprzewodowe (Wi-Fi 4)
Częstotliwość pracy
5 GHz
Prędkość transmisji
Wi-Fi: 150 Mbps (5 GHz)
Odpinana antena
Nie
Porty wej/wyj
2x 10M/100M RJ-45
Port PoE
Tak
